The Lohen adjustable drop links are a precision-machined, lightweight, aluminium upgrade over the standard MINI drop links. They are available in a range of colours and allow you to make adjustments without removing the drop links from your MINI F55, F56 or F57.

Following our step by step tutorial below will help you fit our Lohen F56 front drop links to your MINI. Only a small number of tools are required and the job should take no longer than 1-2 hours.

Tools Required

Lohen F56 front adjustable drop links
17 mm spanner
18 mm spanner
17 mm socket

Removing OEM Drop Links

Step 1 – Remove the front wheel to gain access to the front axle.

Step 2 – Use 17 mm socket to remove old nuts.

Step 3 – Remove the top of the drop link from the top of the shock absorber leg and the bottom of the drop link from the anti-roll bar, and then place to one side, as this part is no longer required.

Installing Lohen Front Drop Links

Step 4 – Insert Lohen drop links into location of previous OEM drop links.

Step 5 – Apply washer to top and bottom of the drop link as shown in the images below

Step 6 – Add nuts and re-tighten to 42 Nm with a 17 mm socket on the nut and 18 mm spanner on the rod end. You have now successfully fitted your Lohen drop links. The drop link is set to OEM specifications.

For adjustments please see step 7.
